3 Components and Power Supply
Rear panel
Fig. 7:
The following table contains information about each connector along with a corresponding description:
Rear panel components
Item
A

3.1.3 Side panel

The following elements are present on the side panel:
Side panel
Fig. 8:
The following table contains information about each connector along with a corresponding description:
Side panel components
Item
A

3.1.4 Underside panel

The following image shows the elements present on the underside panel:
10
Description
Cell connectors: Main and Div.
For further details regarding the Cellular interface, please consult:
- WWAN antenna connection
- WWAN connector on page 30
- Wireless WAN interface on page 34
Description
SIM Card 1-2. A slot where you can insert the SIM cards.
For specific instructions on SIM card installation, please refer to
Installing the SIM card on page 21.
on page 17
