Teldat Regesta Smart PRO Manual page 17

2 Product Overview
E
F
G
H
I
12
LAN Gigabit Ethernet Port.
For more information about the LAN interface, please refer to:
- LAN Connection on page 22
- LAN Connector on page 35
- LAN Interface on page 38
POWER. Power connection.
The Regesta Smart PRO can be powered by either AC or DC power sources, depending on
the specific model.
For details on power connection options, please refer to:
- Power Source on page 20.
- Power Supply Specifications
4xPort Gigabit Ethernet Switch (depending on the model)
For more information about the LAN interface, refer to:
- 4-Port Ethernet Switch Connections
- LAN Switch Connector on page 36
- Switch Interface on page 38
DCE RS-232 serial ports or 2-4 wire RS-485/RS-422.
The hardware of each device (model) determines the configuration of ports.
For more information on the connector used for serial ports such as 2-4 wire RS-
485/RS-422 and DCE RS-232, please refer to:
RS232 option:
- RS-232 Serial Port on page 27
- RS-232 Serial Port Connectors
- RS-232 Serial Interface on page 39
RS485 option
- RS-485/RS-422 Serial Port
- RS-485 Serial Port Connectors
- RS-485 Serial Interface on page 39
RF/WWAN antenna connectors for the Cellular interface (depending on the model).
For more information about the Cellular interface, please refer to:
- WWAN Antenna Connections (RF Connectors)
- WWAN/RF Connectors on page 36
- Wireless WAN Interface on page 39
For more information about SIM installation for the Cellular interface, please refer to
stalling the SIM Card on page 27 .
on page 39
on page 23
on page 37
on page 27
on page 37
on page 24
Teldat S.A.
In-
Regesta Smart PRO
