4 Connecting the Router

Chapter 4 Connecting the Router

This chapter offers a detailed guide on connecting the Regesta Smart PRO router to Ethernet devices and networks.
The following sections are included within this chapter:

4.1 Power Source

Note
Before connecting the router, please take the time to thoroughly read and follow the instructions out-
lined below.

4.1.1 Power Connector Pins

The power connector can be found on the router's connector panel.
Power Supply Connector
Fig. 8:
Depending on the model, the Regesta Smart PRO can be powered by either DC or AC.
Note
Ensure that the power requirements of your device match the power source.
The router uses a 2-wire terminal block with a 5.08 mm pitch for its power connection .
This connector features two terminals, designed for both AC power (in the AC or AC-powered MR models) and DC
20
• Power Source on page 20
• Data Connections on page 22
• Installing the SIM Card on page 27
• RST Button on page 29
• Troubleshooting on page 30
• Updating the Software on page 30
