Technical Information
RED
YELLOW
GREEN
LED behavior in REMOTE mode.
OFF
RED
YELLOW
GREEN
A.3.2.3 ASDP
LED behavior in MASTER and SLAVE modes.
OFF
GREEN
A.3.2.4 ASYNC
LED behavior for the ASYNC protocol.
44
The serial interface is detected,
Unbalanced mode: the interface is awaiting data from the Central site (serial).
Balanced mode: the interface is awaiting data from the Central (serial) and/or Re-
mote sites (IP).
The serial interface is detected and is awaiting data from the Central (serial) and/
or Remote sites (IP). (Transparent mode)
Steady:
Unbalanced mode: Data has been received from the Central site and sent to the
Remote site (IP). Awaiting a response from the Remote site. (Non-transparent
mode)
Balanced mode: Data has been received from the Central site and sent to the Re-
mote site (IP). Awaiting a response from the Remote site. Alternatively, data has
been received from the Remote site and sent to the Central site (serial). Awaiting
a response from the Central site. (Non-transparent mode)
Flashing: Data is being transferred through the serial interface. (For all modes).
The serial interface has not been detected/installed or is configured as DOWN.
The serial interface is detected:
Unbalanced mode: the interface is awaiting data from the Central site (IP).
Balanced mode: the interface is awaiting data from the Central (IP) and/or Remote
sites (serial).
The serial interface is detected and is awaiting data from the Central (IP) and/or
Remote sites (serial). (Transparent mode)
Steady:
Unbalanced mode: Data has been received from the Central site and sent to the
Remote site (serial). Awaiting a response from the Remote site. (Non-transparent
mode)
Balanced mode: Data has been received from the Central site and sent to the Re-
mote site (serial). Awaiting a response from the Remote site. Alternatively, data
has been received from the Remote site and sent to the Central site (IP). Awaiting
a response from the Central site. (Non-transparent mode)
Flashing: Data is being transferred through the serial interface. (For all modes).
The serial interface has not been detected/installed or is configured as DOWN.
Interface is UP.
