Identifying The Sim Trays; Sim Installation Procedure - Teldat Regesta Smart PRO Manual

4 Connecting the Router
Avoid touching the SIM card connectors.
To access the SIM trays, you will need to remove the protective case. For detailed instructions on how to do this,
please refer to the section titled

4.3.1 Identifying the SIM Trays

After removing the case, you will clearly see the elements illustrated below.
The Regesta Smart PRO supports two SIM cards, offering flexibility for various configurations. For example, in-
stalling two SIM cards allows one to function as a backup. To configure this setup, each SIM card must be assigned
to its respective tray, as they have distinct configuration parameters.
The trays are labeled as SIM1 and SIM2, corresponding to socket 1 and socket 2, respectively.
Location of the SIM1 and SIM2 Trays
Fig. 16:

4.3.2 SIM Installation Procedure

After selecting the appropriate SIM card, follow these steps to install it:
(1) Push the fastening in the direction indicated by the arrow labeled OPEN.
(2) Open the upper part of the tray.
(3) Insert the SIM card fully, ensuring that the cut-off corner is on the right side (as shown) using the provided
guides.
(4) Return the tray to its original position.
(5) Press down on the tray and firmly push the fastening toward LOCK until it securely clicks in place.
28
Removing/Installing the Connector Protector on page 15.
Teldat S.A.
Regesta Smart PRO
