- Page 1 Manual Teldat S.A. Regesta-PRO ER B Router Installation Manual Copyright© Teldat DM641-I Version 1.1 /2016 Teldat S.A. Regesta-PRO ER B Router...
- Page 2 This publication is subject to change. Teldat S.A. offers no warranty whatsoever for information contained in this manual. Teldat S.A. is not liable for any direct, indirect, collateral, consequential or any other damage connected to the deliv- ery, supply or use of this manual.
-
Page 3: Table Of Contents
Chapter 2 Regesta-PRO ER B ....... . 3 Characteristics ........ - Page 4 Recycling and the Environment ......Translated Safety Warnings ......Regesta-PRO ER B Router...
-
Page 5: I Related Documents
Related Documents Teldat S.A. I Related Documents Teldat Dm748-I Software Updating Teldat Dm781-I Cellular Interface. Regesta-PRO ER B Router... -
Page 6: Chapter 1 About This Guide
1 About This Guide Teldat S.A. Chapter 1 About This Guide This Regesta-PRO ER B router family installation manual contains information on how to correctly install the router in an appropriate operating environment. 1.1 Supported Devices Information provided in this installation guide only applies to the Regesta-PRO ER B router family. -
Page 7: Chapter 2 Regesta-Pro Er B
Chapter 2 Regesta-PRO ER B 2.1 Characteristics The Regesta-PRO ER B family is a range of IP routers particularly suited to hostile and extreme environments. Thanks to their ruggedized mechanics and special characteristics, which allow them to tolerate extreme temperat- ures, these routers are especially suitable for: industrial environments, industrial telecontrol, distribution installations for electricity, gas, water, etc. -
Page 8: Chapter 3 Components And Power Supply
3 Components and Power Supply Teldat S.A. Chapter 3 Components and Power Supply The following chapter provides information on the Regesta-PRO ER B chassis and its components. This information includes: • Components. • Assembly instructions. • Power supply. • RST button. - Page 9 Coverage level below -100dBm. Cellular interface is not active. Associated to each Ethernet switch Amber ON -> Connection at 100Mbps. connector (LAN1…LAN6). OFF -> Connection at 10Mbps. Associated to each Ethernet switch Green ON -> Ethernet connection (link) es- Regesta-PRO ER B Router...
-
Page 10: Rear Panel
Item Description COM1, COM2. DCE RS-232 serial ports or RS-485 2-4 wires/RS-422. 3.1.3 Underside Panel The following figure shows the underside panel: Underside panel Fig. 5: Underside panel elements are as follows: Underside panel elements table Regesta-PRO ER B Router... -
Page 11: Upper Panel
The kit contains 2 screws to adjust the rail mount to the underside of the device. There are a set of holes on the un- derside allowing you to place the DIN rail mount in two distinct positions: Regesta-PRO ER B Router... -
Page 12: Installing The Protector
The transparent protector prevents the device connectors from being manipulated while it is operating. The transpar- ent protector is not on the device when packed for shipping, it is a separate piece. The following figure shows you how to attach the protector to the device: Regesta-PRO ER B Router... -
Page 13: Power Source
Attaching the transparent protector Fig. 9: 3.3 Power Source The Regesta-PRO ER B can be powered through DC voltage. Nominal power voltage is 48 V DC. Note Before connecting the router, please read the following instructions carefully. Workplace. Main characteristics •... - Page 14 • Make sure the power supply cable is not connected to the device. • Connect all data cables. • Connect the power supply cable to the device. • Connect the power supply cable to the electricity supply. Connecting the power supply to the device Fig. 10: Regesta-PRO ER B Router...
-
Page 15: Rst Button
(located on the front panel) and insert the power cable connector. 3.4 RST Button The Regesta-PRO ER B has (on the front panel) a button that can be accessed from the outside and is labeled RST. This button has two functions: •... -
Page 16: Data Connections
(valid for HSDPA, HSUPA, HSPA+ and LTE technologies). Installing an antenna in the Regesta-PRO ER B is necessary to improve the quality of the signal received and trans- mitted by the WWAN module (GPRS, UMTS, HSDPA, HSUPA, etc.). -
Page 17: Connecting To The Serial Ports
3.5.3 Connecting to the serial ports The Regesta-PRO ER B can have one or various female DB9 connectors, depending on the model. 3.5.3.1 Console connector as serial port (CONF connector) It’s possible to convert the console port into an RS-232 asynchronous DCE serial port. This port has the following characteristics: •... - Page 18 (c) All control signals are available. (d) DB-9 connector. RS-485/RS-422: (a) 2/4 wires configurable through software. (b) Bus termination configurable through software. (c) Maximum speed of 115200 bps. (d) DB-9 connector. RS-232 asynchronous serial connectors Fig. 15: Regesta-PRO ER B Router...
-
Page 19: Chapter 4 Installing The Sim Card
Chapter 4 Installing the SIM card The Regesta-PRO ER B has Wireless WAN interfaces that, in order to operate, may require at least one SIM card to be inserted into the device. There are certain services (CDMA) provided by several carriers in some countries, which do not require SIM cards. -
Page 20: Procedure To Install The Sim
(4) Return the tray to its original position. (5) While pressing on the tray, push the lip in the direction indicated by the word LOCK until it is firmly in place. Inserting the SIM in the internal tray Fig. 18: Regesta-PRO ER B Router... -
Page 21: Appendix A Technical Information
A.2 Updating the software The Regesta-PRO ER B can be updated to new releases. Please contact your distributor for further details on new releases. There are various ways to update a Teldat router. For further information, please see manual “Teldat Dm748-I Soft- ware Updating”... -
Page 22: Connecting To The Router
A.3.1 Connecting through the local console (CONF connector) The Regesta-PRO ER B has a DB-9 female connector on the front panel known as CONF., which provides access to the device local console. To configure this, connect the CONF. port to an asynchronous terminal (or to a PC with ter- minal emulation). -
Page 23: Connectors
• Configure the IP terminal (normally a PC) Ethernet interface with an IP address within the range [192.168.1.2, 192.168.1.254] and with mask 255.255.255.0. E.g. 192.168.1.2, 255.255.255.0. • Connect the IP terminal Ethernet interface to any of the Regesta-PRO ER B router Ethernet Switch ports (LAN1..2) through the Ethernet cable (RJ45) provided. -
Page 24: Rf Connectors
Technical Information Teldat S.A. A.4.3 RF Connectors Internal RF in/out External A.4.4 Configuration Connector DB9 CONFIGURATION CONF A.4.5 RS-232 Serial Port Connectors SERIAL Regesta-PRO ER B Router... -
Page 25: Rs-485 Serial Port Connectors
Depends on the device wireless WAN version. Please see the manual on the rel- evant module. CONNECTOR RF SMA female (optional). ANTENNA Depends on the type of wireless WAN. Please see the catalog on the antennas for cellular interfaces. Regesta-PRO ER B Router... -
Page 26: Configuration Interface
Without protector: 230 x 186 x 50 mm. With protector: 270 x 186 x 50 mm. WEIGHT 650 gr. A.5.9 Environmental Specifications AMBIENT TEMPERATURE ON: -10 °C to +60 °C. OFF: -25 °C to +70 °C. Regesta-PRO ER B Router... -
Page 27: Appendix B Safety Information
B.1 Recycling and the Environment Please do not, under any circumstances, throw away any Regesta-PRO ER B with normal domestic waste. Ask your local town hall for information on how to correctly dispose of them in order to protect the environment against e- waste. -
Page 28: Translated Safety Warnings
Safety information Teldat S.A. B.2 Translated Safety Warnings To Connect To Disconnect Regesta-PRO ER B Router... - Page 29 Safety information Teldat S.A. Regesta-PRO ER B Router...
- Page 30 Safety information Teldat S.A. Regesta-PRO ER B Router...
