2.4.3 Underside Panel

The router's identification label is located on the underside panel. The underside panel has several perforations for
different mounting options. The following figure shows the underside panel:
Underside Panel
Fig. 5:
The following elements can be found on the underside panel:
Table 4: Underside Panel elements table
Item
A
B

2.5 Power Supply

The Regesta Smart PLC AC version is powered from an external AC source. The nominal power voltages are
110-240 V AC.
Regesta Smart PLC
- WWAN/RF Connectors on page 33
- Wireless WAN interface on page 35
Refer to Installing the SIM card
the Cellular interface.
Description
Slots for fixing accessories used to attach the device to a DIN rail mount. For fur-
ther information on this accessory, please see section
Platform where the label containing product information is placed. This label con-
tains information on the device model, MAC, serial number, etc.
on page 23 for more information about SIM installation for
2 Product Overview
Wall mounting on page 15.
