- Page 1 Manual Teldat S.A. Regesta Smart PRO Installation Manual Copyright© Teldat Dm1002-I Version 1.4 09/2023 Teldat S.A. Regesta Smart PRO...
- Page 2 This publication is subject to change. Teldat S.A. offers no warranty whatsoever for information contained in this manual. Teldat S.A. is not liable for any direct, indirect, collateral, consequential or any other damage connected to the deliv- ery, supply or use of this manual.
-
Page 3: Table Of Contents
4.1.1 Power connector pins ....... . . Regesta Smart PRO... - Page 4 WWAN/RF connectors ....... . A.1.6 Configuration connector ....... . Regesta Smart PRO...
- Page 5 Radio Information ....... . . 42 RF WWAN specifications ....... Regesta Smart PRO...
-
Page 6: About This Manual
1 About this Manual Teldat S.A. Chapter 1 About this Manual This is the installation manual for the Regesta Smart PRO router and contains information on how to correctly install the device in a working environment. 1.1 Supported devices The information contained in this manual specifically pertains to the Regesta Smart PRO Series. -
Page 7: Safety Warnings
1 About this Manual Teldat S.A. 1.8 Safety warnings "DC- powered device" "AC-powered device" Regesta Smart PRO... - Page 8 1 About this Manual Teldat S.A. Regesta Smart PRO...
-
Page 9: Related Documentation
1 About this Manual Teldat S.A. 1.9 Related documentation Teldat Dm704-I Configuration and Monitoring Teldat Dm709-I LAN Interfaces Teldat Dm712-I SNMP Agent Teldat Dm781-I Cellular Interface Teldat Dm748-I Software Updating Teldat Dm753-I Syslog Client 1.10 Technical support Contact information: Web: http://www.teldat.com Tel.: +34 918 076 565... -
Page 10: Product Overview
2 Product Overview Teldat S.A. Chapter 2 Product Overview This chapter provides an overview of the features available for Regesta Smart PRO routers and their components. This information includes: • General description on page 5 • Device models on page 6 •... -
Page 11: Device Models
Code Description (Regulatory model) RWRTHR2ZAC Regesta Smart PRO 1 LAN Gigabit Ethernet port, 1 WAN Combo Gigabit Ethernet port, 1 RS232, AC powered (110 - 240 VAC). (TLDPH04D1) RWRTHR2ZDC Regesta Smart PRO 1 LAN Gigabit Ethernet port, 1 WAN Combo Gigabit Ethernet port, 1 RS232, DC powered (12 - 72 VDC). -
Page 12: Hardware Features
VAC). RWRTHR2LAC Regesta Smart PRO 1 LAN Gigabit Ethernet port, 1 WAN Combo Gigabit Ethernet port, 1 RS232, 1xWWAN (Bands: LTE 1, 3, 5, 7, 8, 20, 38, 40, 41 - WCDMA 1, 5, 8 - GSM 3, 8), (TLDPH00D1) AC powered (110 - 240 VAC). -
Page 13: Components
• 1xLTE Category 4 WWAN module with two SMA connectors. • 2 Internal SIM trays with 2FF form factor. • External Reset/Recovery push button 2.4 Components 2.4.1 Front panel The front panel includes the status LEDs. The following figure shows the front panel. Regesta Smart PRO... - Page 14 Cellular interface is not active. corresponding to the active SIM. Coverage level below -100dBm. Amber Coverage level between -90dBm and -100dBm. Green Coverage level above -90dBm. Ethernet LAN inter- The Ethernet LAN is currently disabled or there is no estab- face Regesta Smart PRO...
-
Page 15: Connector Panel
The connector panel is protected by a casing that needs to be removed in order to access it. Please refer to Remov- ing/Installing the connector protector on page 15, for detailed instructions on how to remove or install the protective casing. The following figure shows the panel that contains all the Regesta Smart PRO router connectors. Regesta Smart PRO... - Page 16 WAN Gigabit Ethernet. RJ-45 connector. For more information about the WAN interface with Base-T connector, please refer to: WAN connections on page 23 WAN Base-T connector on page 36 WAN Base-T interface on page 39 LAN Gigabit Ethernet Port. Regesta Smart PRO...
- Page 17 LAN interface on page 39 POWER. Power connection. The Regesta Smart PRO can be powered by either AC or DC power sources, depending on the specific model. For more information about the power connection options, please refer to: Power source on page 20.
-
Page 18: Underside Panel
MAC address, serial number, and more. 2.5 Power supply The Regesta Smart PRO provides three distinct Power Supply options, depending on the specific model. Note Please ensure that you have identified your router model and carefully read the instructions before con-... -
Page 19: Ac Power Supply
2 Product Overview Teldat S.A. 2.5.1 AC power supply The Regesta Smart PRO AC version is powered by an external AC power source. The nominal power voltages that it supports are 110-240 V AC. 2.5.2 DC power supply The Regesta Smart PRO DC version is powered by an external DC power source. The nominal power voltages that it supports are 12-72 V DC. -
Page 20: Installing The Router
3 Installing the Router Teldat S.A. Chapter 3 Installing the Router This chapter describes the steps to successfully install the Regesta Smart PRO router. It is divided into the following sections: • Workplace conditions on page 15 • Removing/Installing the connector protector on page 15 •... - Page 21 3 Installing the Router Teldat S.A. Slide the case up as shown: Regesta Smart PRO...
-
Page 22: Installing A Din Rail Mount
3.3 Installing a DIN rail mount The Regesta Smart PRO includes a DIN rail kit for mounting purposes. This kit consists of 2 screws that are used to attach the DIN rail to the underside of the device. You have the option... -
Page 23: Wall Mounting
Fig. 6: 3.4 Wall mounting The Regesta Smart PRO features 3 wall mounting holes. To ensure a secure attachment, it is necessary to install screws into these holes. Before mounting the device on the wall, please remove the protective casing. - Page 24 3 Installing the Router Teldat S.A. Fig. 7: Wall mounting holes. Regesta Smart PRO...
-
Page 25: Connecting The Router
4 Connecting the Router Teldat S.A. Chapter 4 Connecting the Router This chapter provides a detailed guide on connecting the Regesta Smart PRO router to Ethernet devices and net- works. Within this chapter, you will find the following sections: •... -
Page 26: Power Connector Cable
It is highly recommended to connect all data devices to the same power source, regardless of the work- place having an uninterrupted power supply (UPS), a regulated supply, or being independent of other power supplies (such as lighting). This practice helps prevent malfunctions and premature aging of the drivers and other components. Regesta Smart PRO... -
Page 27: Connecting
The data connections found in the Regesta Smart PRO include: 4.2.1 LAN connection The Regesta Smart PRO comes equipped with a 10/100/1000 BaseT Gigabit Ethernet port. This port supports auto- matic MDI/MDIX to connect to a local area network (LAN). It should be noted that this interface operates independ- ently from any connected switch and functions like any other interface. -
Page 28: Wan Connections
IEC/EN 60825-1:2007 standard. 4.2.3 4-port Ethernet switch connections Certain models of the Regesta Smart PRO router are equipped with a 4-port 10/100/1000 Base-T switch that allows for automatic MDI/MDIX connection to a local area network (LAN). Regesta Smart PRO... -
Page 29: Wwan Antenna Connections (Rf Connectors)
4.2.4 WWAN antenna connections (RF connectors) Certain models of the Regesta Smart PRO router have a pair of RF antenna connectors. The antennas are seam- lessly attached and detached by securely screwing and unscrewing them into the designated RF1 or RF2 connectors located on the device's connector panel. - Page 30 To ensure optimal performance, it is advised to use radio frequency accessories, such as antennas and cables, re- commended by Teldat. Teldat provides various accessories like 90º mount antennas, antennas for outdoor and ceiling installation, extension cables, and more. These accessories offer flexibility in installing the devices at different locations.
-
Page 31: Serial Port Connections
The optional Asynchronous Serial Port feature requires additional hardware. Some models are equipped with two ex- tra serial ports, which are provided through two RJ-45 connectors on the Regesta Smart PRO. Please note that the functionality of these serial ports may vary on certain models. To determine if your device offers serial ports and to obtain information about their type, please refer to the label. -
Page 32: Installing The Sim Card
4.3 Installing the SIM card The Regesta Smart PRO features a Wireless WAN interface that requires at least one SIM card to be inserted for op- eration. However, in certain countries, CDMA services provided by some operators do not require the use of SIM cards. -
Page 33: Identifying The Sim Trays
After removing the case, you will have a clear view of the elements depicted below. The Regesta Smart PRO incorporates 2 SIM cards, providing the flexibility to execute various configurations. For in- stance, by installing two SIM cards, one can serve as a backup. To set up this configuration, you need to assign a separate tray for each SIM, as they have distinct configuration parameters. -
Page 34: Rst Button
WAN port. 4.5 Dying gasp alarm The Regesta Smart PRO offers the option to add a board that enables an alarm to be triggered in case of a power outage or if the power supply cable is removed. -
Page 35: Troubleshooting
For further guidance on SNMP configuration, consult the “Teldat Dm712-I SNMP Agent” manual. (3) If necessary, configure and enable the Syslog feature and server. For additional information on the Syslog feature, please refer to the “Teldat Dm753-I Syslog Client” manual. 4.6 Troubleshooting The table below provides guidance for troubleshooting device installation issues. -
Page 36: Updating The Software
Teldat S.A. 4.7 Updating the software The Regesta Smart PRO router is equipped with the capability to update to new releases. For detailed information on the latest updates, we recommend contacting your distributor. To update one of our routers, there are multiple methods available. For comprehensive instructions, please refer to the “Teldat Dm 748-I Software Updating ”... - Page 37 Teldat S.A. 4.7.1.2 Connecting through an IP terminal (WAN connector) When connecting through an IP terminal, the Regesta Smart PRO will automatically activate its default configuration if no preconfiguration has been done. With the default configuration, the router will establish the following IP address and access mask: •...
-
Page 38: Compliance
+34 91 807 65 65 5.2 Intended use of the equipment The Regesta Smart PRO is specifically designed as an industrial router. Operating this equipment in a residential en- vironment may cause potential radio interference. 5.3 EC declaration of conformity (non-radio version) English (EN) Teldat S.A. -
Page 39: Ec Declaration Of Conformity (Radio Version)
In accordance with Article 10 of 2014/53/EU, we inform you that there may be national restrictions and requirements for authorization, which can change over time. Teldat S.A. recommends checking with local authorities for the most up-to-date information regarding national regulations. -
Page 40: Weee Information
El símbolo del contenedor con la cruz, que se encuentra en el aparato, significa que cuando el equipo haya llegado al final de su vida útil, deberá ser llevado a los centros de recogida previstos, y que su tratamiento debe estar separado del de los residuos urbanos. Regesta Smart PRO... -
Page 41: Appendix A Technical Information
BI-DC+ BI-DC- BI-DB- BI-DB- BI-DD+ BI-DD- A.1.2 WAN Base-T connector RJ45 WAN RJ45 PIN FE Signals GE Signals BI-DA+ BI-DA+ BI-DA- BI-DA- BI-DB+ BI-DB+ BI-DC+ BI-DC- BI-DB- BI-DB- BI-DD+ BI-DD- A.1.3 WAN SFP connector Standard SFP connector Regesta Smart PRO... -
Page 42: Lan Switch Connector
BI-DB+ BI-DC+ BI-DC- BI-DB- BI-DB- BI-DD+ BI-DD- A.1.5 WWAN/RF connectors Devices featuring this interface are equipped with two SMA female connectors. SMA Female Internal RF in/out External A.1.6 Configuration connector RJ45 CONFIGURATION CONF TxD (input) RxD (output) Regesta Smart PRO... -
Page 43: Rs-232 Serial Port Connectors
2-wire 5.08 mm pitch terminal - AC-powered version: block Phase and Neutral connectors without assignation. - DC-powered version: V+ and V- connectors with polarity. A.2 Technical specifications A.2.1 Hardware architecture MEMORY 128 Mbytes in SDRAM. STORAGE UNIT FLASH Memory (32 Mbytes). Regesta Smart PRO... -
Page 44: Lan Interface
Standard for E1 interface (1.5 KV). A.2.5 WAN SFP interface STANDARDS 802.1Q (VLAN). 1000-Base-X. MSA and SFF 8472 compliant. SPEED 1000 Mbps full duplex. TYPES LX/LH (single-mode 1310 nm). SX (multi-mode 850 nm). ZX (single-mode 1550 nm). CONNECTOR Standard SFP connector. Regesta Smart PRO... -
Page 45: Wireless Wan Interface
RJ-45 female on the connector panel (optional). A.2.9 RS-485 serial interface STANDARDS 2-4 wire RS-485/RS-422 configurable via software. Bus termination configurable via software. SPEED From 300 to 115200 bps. CONNECTOR RJ-45 female on the connector panel (optional). A.2.10 Power supply specifications Regesta Smart PRO... -
Page 46: Dimensions And Weight
LENGTH x WIDTH x HEIGHT 140 x 80 x 190 mm. WEIGHT 1 Kg. A.2.12 Environmental specifications TEMPERATURE RANGE OPERATION: -20 ºC to +70 ºC STORAGE: -25º to +70 ºC RELATIVE HUMIDITY 5 % to 93 % Regesta Smart PRO... -
Page 47: Appendix B Radio Information
Teldat S.A. Appendix B Radio Information B.1 RF WWAN specifications The Regesta Smart PRO model, equipped with the EC25 module, offers network connectivity across multiple radio frequency bands, in line with the latest 3GPP Standards. • LTE (3GPP Release 10), •... - Page 48 Tx: 824–849 MHz +33 dBm ± 2 dB Rx: 869–894 MHz +27 dBm ± 3 dB (8-PSK) PCS 1900 (1900 MHz) Tx: 1850–1910 MHz +30 dBm ± 2 dB Rx: 1930–1990 MHz +26 dBm ± 3 dB (8-PSK) Regesta Smart PRO...
