4.1 Jumpers and Connectors

4.1.1 Jumper Configuration

Users can configure UTC-320 according to their application needs by setting jump-
ers. A jumper is the simplest type of electrical switch and consists of two metal pins
and a small metal clip (typically protected by a plastic cover) that slides over the pins
to connect them. To close a jumper, connect the pins with the clip. To open a jumper,
simply remove the clip. Some jumpers have three pins, labeled 1, 2, and 3. For this
type of jumper, connect either Pins 1 and 2, or Pins 2 and 3.
The jumper settings are schematically depicted below.
A pair of needle-nose pliers may be helpful when working with jumpers. For advice
regarding the optimum hardware configuration for specific applications, contact your
local distributor or sales representative.
UTC-320 User Manual
open
open
closed
closed closed 2-3
22
closed 2-3
