Table A.9: LVDS1(I):LVDS
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
UTC-320 User Manual
1655005099-01
LVDS_40P_50203-04001-001
LVDS Conn. 40P 0.5mm 90D(F) SMD 50203-04001-001
Pin name
+3.3V
+3.3V
+3.3V
+3.3V
LVDS0_D0-
LVDS0_D0+
GND
LVDS0_D1-
LVDS0_D1+
GND
LVDS0_D2+
LVDS0_D2-
GND
LVDS0_CLK-
LVDS0_CLK+
GND
LVDS0_D3-
LVDS0_D3+
GND
LVDS1_D0-
