Table A.47: CN23(D),CN17(EFG): LAN1/LAN2
Part Number 1652003274
Footprint RJ45_28P_RTB-19GB9J1A
Description PHONE JACK RJ45 28P DIP RTB-19GB9J1A
Pin Pin name
Table A.48: CN11(H): LAN1/LAN2
Part Number 1652006625-01
Footprint RJ45_28P_RTB-19GB9J4A
Description PHONE JACK RJ45 28P 2.54mm DIP RTB-19GB9J4A
Pin Pin name
Table A.49: CN11(I): LAN1/LAN2
Part Number 1654015289-01
Footprint RJ45_28P_RTB-ZZ-0044
Description RJ45 1X2 28P/PA6T/G-FL/RA/D/BK/G,O;G/W SP
Pin Pin name
Table A.50: CN5(K): LAN1
Part Number 1654013536-01
Footprint RJ45_8P_RT13-ZZ-0003
Description RJ45 8P/LCP/F/RA/GFL/D/BK/H7.S/L1.6mm/pure
Pin Pin name
Table A.51: CN111(K): LAN2
Part Number 1654015322-01
Footprint RJ45_15P_RS3-ZZ-0004
Description RJ45 1X1 15P/PA6T/RA/G-FL/BK/S/G,O;G/SINK/SLIM
Pin Pin name
67 UTC-320 User Manual
