Advantech UTC-320 User Manual page 62

Table A.24: CN13(D),DIMM(EG): DDR3L SODIMM
Part Number
Footprint
Description
Pin
Table A.25: DIMM(F),CN1(H), DIMMA1(I): DDR4 SODIMM
Part Number
Footprint
Description
Pin
Table A.26: U17(K): DDR5 SODIMM
Part Number
Footprint
Description
Pin
Table A.27: MINIPCIE1(DEF): MINIPCIE
Part Number
Footprint
Description
Pin
1
2
3
4
5
UTC-320 User Manual
1651002087-11
DDR3_204P_AS0A626-N2S6-7H
DDR3 SODIMM H=5.2mm STD 204P SMD AS0A626-H2S6-7H
Pin name
1651002829-01
SODIMMDDR4_260P_AS0A826-H2SB
DDR4 SODIMM H=5.2mm 260P SMD AS0A826-H2SB-7H STD
Pin name
1651003727-01
SODIMDDR5_262P_ASAAC27-J2SB0-7H
DDR5 SODIMM 262P/0.5mm/G15u/RA/S/BK/H5.2/STD
Pin name
1654002538
FOX_AS0B226-S68K7F
MINI PCI E 52P 6.8mm 90D SMD AS0B226-S68Q-7H
Pin name
MPCIE1_WAKE#
+3.3VSB
NC
GND
NC
52
