- Page 1 User Manual UNO-2484G 電腦 ® Intel Core™ i Standard-Size Automation Computer with 4 x GbE, 1 x mPCIe, HDMI, DP, 4 x USB3.0, 4 x COM...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 UNO2484G6531907E-T, UNO2484G6531908E-T, UNO2484G6531909E-T, UNO2484G6532001E-T, UNO2484G6532002E-T, UNO2484G6532003E-T, UNO2484G6532004E-T, UNO2484G6532005E-T, UNO2484G6532006E-T, UNO2484G6532007E-T, UNO2484G6532008E-T, UNO2484G6532009E-T, UNO2484G6532101E-T, UNO2484G6532102E-T, UNO2484G6532103E-T, UNO2484G6532104E-T, UNO2484G6532105E-T, UNO2484G6532106E-T, UNO2484G6532107E-T, UNO2484G6532108E-T, UNO2484G6532109E-T, UNO2484G6532201E-T, UNO2484G6532202E-T, UNO2484G6532203E-T, UNO2484G6532204E-T, UNO2484G6532205E-T, UNO2484G6532206E-T, UNO2484G6532207E-T, UNO2484G6532208E-T, UNO2484G6532209E-T, UNO2484G6331701E-T, UNO2484G6331702E-T, UNO2484G6331703E-T, UNO2484G6331704E-T, UNO2484G6331705E-T, UNO2484G6331706E-T, UNO2484G6331707E-T, UNO2484G6331708E-T, UNO2484G6331709E-T, UNO-2484G User Manual...
- Page 4 UNO2484G6331807E-T, UNO2484G6331808E-T, UNO2484G6331809E-T, UNO2484G6331901E-T, UNO2484G6331902E-T, UNO2484G6331903E-T, UNO2484G6331904E-T, UNO2484G6331905E-T, UNO2484G6331906E-T, UNO2484G6331907E-T, UNO2484G6331908E-T, UNO2484G6331909E-T, UNO2484G6332001E-T, UNO2484G6332002E-T, UNO2484G6332003E-T, UNO2484G6332004E-T, UNO2484G6332005E-T, UNO2484G6332006E-T, UNO2484G6332007E-T, UNO2484G6332008E-T, UNO2484G6332009E-T, UNO2484G6332101E-T, UNO2484G6332102E-T, UNO2484G6332103E-T, UNO2484G6332104E-T, UNO2484G6332105E-T, UNO2484G6332106E-T, UNO2484G6332107E-T, UNO2484G6332108E-T, UNO2484G6332109E-T, UNO2484G6332201E-T, UNO2484G6332202E-T, UNO2484G6332203E-T, UNO2484G6332204E-T, UNO2484G6332205E-T, UNO2484G6332206E-T, UNO2484G6332207E-T, UNO2484G6332208E-T, UNO2484G6332209E-T, UNO-2484G User Manual...
- Page 5 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 6 這是甲類測試產品，在居住的環境中使用時，可能會造成射頻干擾，在這種情況下， 使用者會被要求採取某些適當的對策。 Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...
- Page 7 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
- Page 8 9. 請將電源線佈置在人們不易絆倒的位置，請勿在電源線上覆蓋任何雜物。 10. 請注意設備上所有的警告標示。 11. 如果長時間不使用設備，請拔除與電源插座的連結，避免設備被超標的電 壓波動損壞。 12. 請勿讓任何液體流入通風口，以免引起火灾或短路。 13. 請勿自行打開設備。為了確保您的安全，請透過經認證的工程師來打開設 備。 14. 如遇下列情况，請由專業人員維修： 電源線或插頭損壞； 設備內部有液體流入； 設備曾暴露在過度潮濕環境中使用； 設備無法正常工作，或您無法透過用戶手冊來正常工作； 設備摔落或損壞； 設備有明顯外觀損； 15. 請勿將設備放置在超出建議溫度範圍的環境，即不要低於 -20℃ （‐4℉）或 高於 60℃ （140℉） ，否則可能會造成設備損壞。 16. 注意：若電池更換不正確，將有爆炸危險。因此，只可以使用製造商推薦 的同一種或者同等型號的電池進行替換。請按照製造商的指示處理舊電池。 17. 根據 IEC 704‐1:1982 規定，操作員所在位置音量不可高於 70 分貝。 18. 限制區域：請勿將設備安裝於限制區域使用。 19. 免責聲明：請安全訓示符合 IEC 704‐1 要求。研華公司對其內容之準確性不 承擔任何法律責任。 UNO-2484G User Manual viii...
-
Page 9: Table Of Contents
Hardware Functionality .......5 Introduction ....................6 Figure 2.1 Front Panel of UNO-2484G for one stack model which can support extra extension kit UNO-2484G-EKAE ... 6 Figure 2.2 Front Panel of UNO-2484G for two stack model which can support extra iDoor module ......... 6 UNO-2484G Interface ................ - Page 10 UNO-2484G User Manual...
-
Page 11: Chapter 1 Overview
Chapter Overview This chapter provides an overview of UNO-2484G specifications. Sections include: Introduction Safety precautions Accessories... -
Page 12: Introduction
UNO-2484G includes Intel’s latest Skylake Core- itechnology and provides rich interfaces including up to 4 x GbE LAN and 4 x USB3.0 ports. The UNO-2484G supports one DP and one HDMI display and also Advan- tech’s latest iDoor technology. -
Page 13: Accessories
Accessories Please refer below for the accessory list: Pin connector for power wiring (Advantech P/N: 1652002209) Warranty card If anything is missing or damaged, contact your distributor or sales representative immediately. Operating Temperature: -20 to 60°C ... - Page 14 UNO-2484G User Manual...
-
Page 15: Chapter 2 Hardware Functionality
Chapter Hardware Functionality This chapter shows how to setup the UNO-2484G’s hardware func- tions, including connecting peripherals, setting switches and indicators. Sections include: Introduction UNO-2484G Interface LAN / Ethernet Connector Power Connector USB Connector RTC Battery Specification ... -
Page 16: Introduction
The following figures show the connectors on UNO-2484G. The following sections give you information about each peripheral. Figure 2.1 Front Panel of UNO-2484G for one stack model which can support extra extension kit UNO-2484G-EKAE Figure 2.2 Front Panel of UNO-2484G for two stack model which can support... -
Page 17: Power Connector
3.0 compliant. Refer to Appendix A.5 for its pin assignments. RTC Battery Specification The UNO-2484G has an RTC Battery to ensure the setting in BIOS and system clock can be kept, even with power disconnected for a short time. ... - Page 18 The UNO-2484G supports one socket full size PCI Express mini cards. UNO-2484G User Manual...
-
Page 19: Chapter 3 Initial Setup
Chapter Initial Setup This chapter introduces how to initialize the UNO-2484G. Sections include: Inserting aM.2 Chassis Grounding Connecting Power Installing a Wireless LAN Card and Antenna... -
Page 20: Chassis Grounding
Chassis Grounding UNO-2484G provides good EMI protection and a stable grounding base. There is an easy-to-connect chassis grounding point to use. Figure 3.1 Chassis Grounding Connection Connecting Power This product is intended to be supplied by a Listed Power Adapter or DC power source, rated at 10 - 36Vdc, 2A and Tma 60 degree C, if you need further assistance, please contact Advantech for further information. -
Page 21: System Settings And Pin Assignments
Appendix System Settings and Pin Assignments... -
