A.1 Pin Assignments
Table A.1: CN1(DE),CN2(FGH):Back Light
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
8
Table A.2: CN2(I):Back Light
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
8
UTC-320 User Manual
1655004512-01
WF_8P_49_BOX_D
WAFER BOX 8P 1.25mm 180D(M) DIP A1251WV0-8P
Pin name
+12V_INVERTER
+12V_INVERTER
GND
GND
BKLT_EN
BRIGHT1
+12V_INVERTER
GND
1653008044-01
WF_8X1P_49_D_H185
Wafer 1X8P/1.25/HTN/Sn/VA/D/WH/L2.30mm
Pin name
+12V_INVERTER
+12V_INVERTER
GND
GND
BKLT_EN
BRIGHT1
+12V_INVERTER
GND
