Table A.29: CN14(D),CN10(F),CN7(GHI): COM4
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
8
9
Table A.30: CN15(D), CN12(F),CN9(G),CN96(HI): COM3
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
8
9
UTC-320 User Manual
1655000197
WF_5x2P_79_BOX_D_P1R
1655_WF_5x2P_79_BOX_D_P1R_0.Normal
Pin name
DCD
RXD
TXD
DTR#
GND
DSR#
RTS#
CTS#
RI#
1655000197
WF_5x2P_79_BOX_D_P1R
1655_WF_5x2P_79_BOX_D_P1R_0.Normal
Pin name
DCD
RXD
TXD
DTR#
GND
DSR#
RTS#
CTS#
RI#
