Table A.42: CN16(H): M.2_2230
Part Number
Footprint
Description
Pin
1,7,18,33,39,45
51,57,63,69,75,H4
57,71,73,75,H3,H4
2,4,72,74
50
54
56
58
60
3
5
35
37
47
49
53
UTC-320 User Manual
1654013690-01
NGFF_75P_APCI0085-P003A
NGFF 75P/0.5/F/LCP+40GF/RA/G10u/S/BK/H3.0/E Key
Pin name
GND
GND
GND
3.3V
SUSCLK_z_EKEY
BT_DISABLE#
WIFI_DISABLE#
I2C0_KEYE_DAT
I2C0_KEYE_CLK
USB8_z_P+
USB8_z_P-
PCIE_M2_z_TX7+
PCIE_M2_z_TX7-
CLK_M2E_z_PCIE+
CLK_M2E_z_PCIE-
PCIE_a_CLKREQ2#
62
