Advantech UTC-320 User Manual page 40

Table 4.8: JP4(HI):TS POWER
Setting
(1-2)
Table 4.9: JP4(D),JP5(EGK),JP7(F),JP8(HI):AT/ATX POWER SEL
Part Number
Footprint
Description
Setting
(1-2)
(2-3)*
Table 4.10: CN17(DK):COM1 Ring
Part Number
Footprint
Description
Setting
(1-2)
(3-4)*
(4-5)*
Table 4.11: CN9(EF),CN14(G),CN18(HI):COM1,COM2 Ring
Part Number
Footprint
Description
Setting
(1-3)
(2-4)
(3-5)*
(4-6)*
(7-9)*
(8-10)*
UTC-320 User Manual
Function
3.3V
1653003101
HD_3x1P_79_D
PIN HEADER 3*1P 180D(M) 2.0mm DIP 2000-13 WS
Function
AT
ATX
1653005101
HD_5x1P_79_D
PIN HEADER 5x1P 2.0mm 180D(M) DIP 1140-000-05SN
Function
RING
COM1 RI output +5V
COM1 RI output +12V
1653005261
HD_5x2P_79
PIN HEADER 5x2P 2.0mm 180D(M) SMD 21N22050
Function
COM1 RING
COM2 RING
COM1 RI output +5V
COM2 RI output +5V
COM1 RI output +12V
COM2 RI output +12V
30
