Table A.8: LVDS1(H):LVDS
14 LVDS1_D1-
15 LVDS0_D1+
16 LVDS1_D1+
17 GND
18 GND
19 LVDS0_D2-
20 LVDS1_D2-
21 LVDS0_D2+
22 LVDS1_D2+-
23 GND
24 GND
25 LVDS0_CLK-
26 LVDS1_CLK-
27 LVDS0_CLK+
28 LVDS1_CLK+
29 GND
30 GND
31 LVDS0_D3-
32 LVDS1_D3-
33 LVDS0_D3+
34 LVDS1_D3+
35 UD
36 RL
37 +5V
38 +5V
39 GND
40 GND
43 GND
44 GND
