Advantech UTC-320 User Manual page 58

Table A.14: CN11(DF),CN10(G) VGA
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Table A.15: SATA(DEFG): SATA
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
UTC-320 User Manual
1653208260
HD_8x2P_79_BOX
BOX HEADER 8x2P 2.00mm 180D(M) SMD 23N6850
Pin name
VGA_R
+5V
VGA_G
GND
VGA_B
NC
NC
VGA_DDAT
GND
VGA_HS
GND
VGA_VS
GND
VGA_DCLK
GND
GND
1654004659
WF_5P_98_BOX_D
WAFER BOX 5P 2.5mm 180D(M) DIP 2503-WS-5
Pin name
GND
TX+
TX-
GND
RX+
RX-
GND
48
