UTC-320D/E/F/G I/O Port
A
A. COM port
C. Mic-In (Line-out UTC-320G) D. 2 x Gigabit LAN
E. HDMI/VGA
G. RJ-11 (optional)
I. DC-In
UTC-320H/I IO Port
A B
A. COM1
C. Mic-In
E. 2 x LAN ports
G. DP (Only for UTC-320H)
I. DC input 12-30V
UTC-320K I/O Port
A B C
A.
A. Power button
B. USB Type-C DC IN
C. USB Type-C Only
D. 2 x LAN
E. 2 x USB 3.2
B D E
C
B. Line-Out (Mic-in UTC-320G)
F. 4 x USB 3.0, 2 x USB 2.0 (Core™ and Pentium®)
5 x USB 2.0, 1 x USB 3.0 (Celeron®)
H. Power button
C D E F
B. COM2
D. Line-Out
F. HDMI
H. 6 x USB 3.1 (UTC-320H)/2 x USB 2.0 and
4 x USB 3.2 (UTC-320I)
J. Power Button
D E F
F. HDMI
G. 2 x RJ-48 (COM)
H. Line out/ Mic-In
I. 2 x USB 2.
9
F G H
G H I
G H I
