4.2 Jumpers

4.2.1 Jumper List

Table 4.2: Jumper List
JP1(D),JP3(EF)
JP3(D),JP6(E),JP5(FHI),JP4(G), JCMOS1(K)
JP4(HI)
JP4(D),JP5(EG),JP7(F),JP8(HI)JP5(K)
CN17(DK),CN9(EF),CN14(G),CN18(HI)
JCASH1
CN10(E)
JP1(HI) JP2(K)
JP2(HI) JP1(K)

4.2.2 Jumper Settings

Table 4.3: JP1(D),JP3(EF):LCD POWER
Part Number
Footprint
Description
Setting
(1-2)
(2-3)*
Table 4.4: JP1(HIK):PWM POWER
Part Number
Footprint
Description
Setting
(1-2)
(2-3)*
UTC-320 User Manual
1653003100
HD_3x1P_100_D
PIN HEADER 3x1P 2.54mm 180D(M) DIP 205-1x3GS
Function
5V
3.3V
1653003101
HD_3x1P_79_D
PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-13 WS
Function
5V
3.3V
28
LCD POWER
Clear CMOS
TS POWER
AT/ATX POWER SEL
COM1,COM2 RING
Cash drawer power
CSAFE POWER
PWM Power
BKLT_EN Power
