Advantech UTC-320 User Manual page 51

Table A.9: LVDS1(I):LVDS
21 LVDS1_D0+
22 GND
23 LVDS1_D1-
24 LVDS1_D1+
25 GND
26 LVDS1_D2-
27 LVDS1_D2+
28 GND
29 LVDS1_CLK-
30 LVDS1_CLK+
31 GND
32 LVDS1_D3-
33 LVDS1_D3+
34 GND
35 +3.3V
36 +5V
37 +V5
38 +5V
39 +V5
40 +V5
H1 Float
H2 Float
H3 GND
H4 GND
H5 GND
H6 GND
H7 GND
H8 GND
41 UTC-320 User Manual
