Advantech UTC-320 User Manual page 70

Table A.38: CN22(D),CN15(E),CN16(FG),CN168(H): SPEAKER
Part Number
Footprint
Description
Pin
1
2
3
4
Table A.39: CN168(I): SPEAKER
Part Number
Footprint
Description
Pin
1
2
3
4
Table A.40: CN23(K),CN25(K): SPEAKER
Part Number
Footprint
Description
Pin
1
2
UTC-320 User Manual
1655304020
WF_4P_79_BOX_R1_D
WAFER BOX 2.0mm 4P 180D(M) W/LOCK A2001WV2-4P
Pin name
AUD_OUTA-
AUD_OUTA+
AUD_OUTB+
AUD_OUTB-
1655000674-01
WF_4P_79_BOX_D_721-81-04TW0
WAFER BOX 4P 2.00mm 180D(M) DIP 721-81-04TW00
Pin name
SPK_L-
SPK_L+
SPK_R+
SPK_R-
1653008407-01
WF_2P_49_BOX_50275-0020C-006
Wafer 1x2P/1.25/VA(M)/G15u"/D/WH/H4.3/L2.3/Reel
Pin name
SPK_R-
SPK_R+
60
