Display Settings - Sunrise Medical Quickie R-Net Control System Instructions For Use Manual

Fig.7.9
Set Time
Display Time
Distance
Backlight
Background
Exit
Fig.7.10
Set Time
Display Time
Distance
Backlight
Background
Exit
Fig.7.11
Set Time
Display Time
Distance
Backlight
Background
Exit
247555 Rev. A

7.5 Display Settings

Backlight (Fig 7.9)
>
This sets the intensity of the LCD backlight.
The adjustable range is 0% to 100% in steps of 10%.
>
• Move the joystick backwards until "Backlight" is highlighted.
>
• Deflect the joystick to the right to increase the value.
<100%>
• Deflect the joystick to the left to decrease the value.
• Move the joystick backwards or forwards to go back to the
<Blue>
>
Background (Fig 7.10)
This sets the color of the screen background. Blue is the
standard, but in very bright sunlight then a white background
will make the display more visible (Fig 7.11).
The options are Blue, White, and Auto.
• Deflect the joystick backwards until "Background" is
• Move the joystick to the right to select, "Blue, White, or Auto."
• Deflect the joystick backwards or forwards to exit
>
Blue means the background will be blue in all Profiles.
<12hr>
White means the background will be white in all Profiles. Auto
means the color will be set by the installed program. For
>
example, blue could be for the slower Profiles that are for indoor
use and white for the faster Profiles intended for outdoor use.
<100%>
For more details of this parameter, please contact your
authorized dealer.
<Blue>
>
Exit
• Move the joystick backwards until "Exit" is highlighted.
• A right joystick deflection will return to the Settings Menu
>
<12hr>
>
<100%>
<White>
>
28
Settings screen.
highlighted.
"Background."
(Fig 7.8).
R-Net Control System
