Pairing Multiple Pc's - Sunrise Medical Quickie R-Net Control System Instructions For Use Manual

Add Bluetooth Device Wizard
Fig.18.13
Bluetooth Devices
Devices Options COM Ports Hardware
Peripherals (keyboard, mice, joysticks)
R-Net Bluetooth Mouse Module
Passkey enabled
Connected
Add...
Remove
OK
Fig.18.14
247555 Rev. A
Completing the Add Bluetooth
Device Wizard
The Bluetooth device was successfully connected to your
computer. Your computer and the device can communicate
whenever they are near each other.
To close the wizard, click Finish
< Back
Properties
Apply
Cancel
65
Finish Cancel
10. Click "Use the pass key found in documentation"
(Fig 18.11)
11. Enter a pass key of "0000" then click "Next" (Fig 18.11).
12. The PC will connect with the Mouse Module and
exchange (Fig 18.12).
13. Once connection is complete the Finish screen will be
displayed (Fig 18.13).
14. Click on "Finish" (Fig 18.13).
15. The following window will be shown and the blue LED on
the Bluetooth Module should be lit (Fig 18.14).
16. If the process fails, click on "R-Net Bluetooth Mouse
Module" and then "Remove" (Fig 18.14).
Start the process again from step 1.

18.9 Pairing Multiple PC's

When you are within range of the new PC requiring connection,
follow steps 1 to 16, as described in Section 18.8.
WARNING!
The R-Net Mouse Module should only be paired with one PC
stationed within a 82' (25m) range. Where multiple pairings
take place within a 82' (25m) range, Sunrise Medical
accepts no liability for any losses of any kind due to the
effectiveness of the R-Net Mouse Module.
R-Net Control System
