Settings Menu; Set Time - Sunrise Medical Quickie R-Net Control System Instructions For Use Manual

Fig.7.0
PRESS and HOLD
MODE
Fig.7.1

Set Time

Display Time
Distance
Backlight
Background
Exit
Fig.7.2
Set Time
2009
Feb 4
Exit
247555 Rev. A
PROFILE
>
>
<100%>
<Blue>
>
Wed 16 : 43

7.0 Settings Menu

7.1 Settings Menu
The Settings Menu allows you to adjust the LCD display in
terms of clock adjustment and display format, the brightness
of the backlight, the background color and the behavior of
the odometer. The menu is accessed by depressing and
holding the Profile Button (Fig 7.0).
A Settings Menu display example is shown in Fig 7.1.
Each of the menu items are described in the following
sections:
7.2 Set Time
• Deflecting the joystick to the right will enter the clock
adjustment screen (Fig 7.2).
• Six adjustable parameters are displayed on the clock
adjustment screen:
• Year, Month, Date, Day, Hours and Minutes. The Exit option
is also displayed (Fig 7.2).
• Deflecting the joystick forwards will increase the selected
parameter, deflecting the joystick backwards decreases the
selected parameter.
• Deflecting the joystick to the right selects the next parameter,
deflecting the joystick to the left selects the previous
parameter.
• When the date/time is set, a final deflection to the right to
select Exit, then forwards or backwards, exits the clock
adjustment screen.
25 R-Net Control System
