21.0 CJSM2 Bluetooth Setup and Operation

21.1 Introduction

The R-Net CJSM2-BT allows a wheelchair user to control
multiple Bluetooth enabled devices. Typical applications
include PC mouse control or operation of a Smart device.
Up to four devices can be controlled. Two of which can be
Apple iOS devices and two of which can be Windows or
Android devices.

21.2 Operation and Configuring

Bluetooth Mode will only be available if one or more devices
are set to On in the Settings Menu. See section Bluetooth
Mode Screen Configuration for more details.
The CJSM2-BT and target Bluetooth devices will remain paired
until they are disconnected by the target device.
Once a CJSM2-BT has been paired with a Bluetooth device,
the module remembers the device's unique identifier. This
means the wheelchair can be driven outside the operating
range of the Bluetooth connection and upon returning within
range the connection will be automatically reinstated.
There are three configuration processes that need to be carried
out:
• Bluetooth Mode configuration.
• Bluetooth Mode screen configuration.
• Pairing with Bluetooth Devices.
Each is described in the following sections.
An R-Net Output Mode must be set to Bluetooth. Please
contact your Sunrise Medical authorized dealer.
This is a two-stage process. Firstly, a device or devices must
be set to On from the Settings Menu. Secondly, for each
device a screen graphic and a name can be set via PC
Programing. The following two sections describe each process.
Settings Menu
• Enter the Settings Menu and select Bluetooth.
• The Bluetooth Devices screen is displayed.
• Set one or more of the devices to On.
• Switch the R-Net system off and on again (Refer to Fig 21.1).
247555 Rev. A
Fig.21.1
