18.5 System Integration
A Mouse Module can be fitted at any point within an
R-Net Control System. See Fig 18.1 and 18.2.
Power Module
Fig.18.1
OMNI SYSTEM
Power Module
Fig.18.2
247555 Rev. A
JSM SYSTEM
Bluetooth Mouse Module
Communication Cable
Bluetooth Mouse
Module
Communication Cable
60
Joystick Module
Communication Cable
Special
Input
Device
Communication Cable
Omni
R-Net Control System
