Switch Control Setup
Certain CJSM2-BT commands can be assigned to iDevice
commands. The CJSM2-BT commands are detailed
below. Time related deflections (nudges) of the joystick in
each of the four directions (Fig 21.10).
• Forward Short
• Reverse Short
• Left Short
• Right Short
• Forward Medium
• Reverse Medium
• Left Medium
• Right Medium
• Forward Long
• Reverse Long
• Left Long
• Right Long
The timings associated with the nudges are programable.
Refer to the Bluetooth Programing chapter for more
information.
Set the R-Net programable parameter Mode to Switch
Control. Refer to the Bluetooth Programing chapter for more
information.
NOTE:
Within Accessibility there are Auto Scanning and Auto Hide
options. It is recommended that these options are turned off
for the initial set up.
To enable Switch Control on the iDevice and assign
commands:
• From the iDevice Settings menu, select General >
Accessibility (Fig 21.21).
• Set Switch Control to ON (Fig 21.22).
• Select Switches (Fig 21.23).
• Select External (Fig 21.24).
• Select Add New Switch (Fig 21.25).
• This screen is displayed (Fig 21.26).
• Activate the CJSM2-BT command you wish to assign to the
iDevice; for example, a long reverse nudge.
• When the command has been received, this screen is
displayed (Fig 21.27).
• Enter a convenient name – for example, long reverse – and
then Save (Fig 21.28).
• This screen is displayed (Fig 21.29).
• Select the iDevice command you wish to assign; for
example, Move To Next Item (Fig 21.29).
• This screen will appear and the process can be repeated to
assign further commands (Fig 21.30).
247555 Rev. A
Fig.21.21
Fig.21.22
Fig.21.23
Fig.21.24
