FUNCTION
Drive*
x Profile x**
Profile
Seating*
Seating* 2
Seating*
Speed Adjust
Mode x to y*
Sleep
Lights
Exit
Settings
*
**
Fig.14.2
14.4 Operation with Joystick Type SIDs (Fig 13.2)
Driving is via the SID's joystick and the User Switch is used
to enter the User Menu.
There are several standard R-Net programming features
that may be useful when using this SID type. These
include joystick throw, joystick orientation and joystick
deadband. Refer to your health care professional or
authorized dealer.
Standard control of seating movement is via Forward and
Reverse commands, and Left and Right commands will
select a different seat axis for movement.
Please refer to Section 14.6.
If required, it is possible to re-program the Omni to control
the seating movement in alternative ways. Refer to your
health care professional or authorized dealer.
For latched operation using this SID type, refer to section
Latched Operation.
247555 Rev. A
> Will enter Drive Mode in the currently selected Profile
> Will enter Drive Mode in the indicated Profile
<X> Sets the Profile that is used the next time Drive Mode is entered
> Will enter Seating Mode
> Will enter a second Seating Profile. Eg. If non-latched and latched
operation is required.
<X> Sets the Seating Profile that is used the next time Seating Mode is
entered
<X> Adjusts the maximum speed settings
> Displays modes x to y in turn, Eg. PC Mouse, Environmental etc.etc.
> Will put the Omni into Sleep Mode
> Will enter Lighting Control Mode
> Will exit the Menu and enter the Drive Mode in the presently selected
Profile
> Allows access to user settings such as backlight, background color
and clock adjustment
The text will reflect the setting of the standard R-net parameter Mode
Name.
The text will reflect the setting of the standard R-net parameter Profile
Name.
OPERATION
14.5 Operation with Switch Type SIDs (Fig 13.3)
Driving is via the SID's Forward, Reverse, Left and Right
switches, and the fifth switch or User Switch is used to
enter the User Menu.
There are several standard R-net programing features
that may be useful when using this SID type. These
include joystick orientation. Refer to your health care
professional or authorized dealer.
Standard control of seating movement is via Forward and
Reverse buttons, and Left and Right buttons will select a
different seat axis for movement.
Please refer to Section 14.6
If required, it is possible to re-program the Omni to
control the seating movement in alternative ways. Refer
to your health care professional or authorized dealer.
For latched operation using this SID type, refer to section
Latched Operation.
