Sip
Soft
Threshold
Marker
Fig.13.8
Soft and Hard Puffs
Now repeat the sequence of instructions for both soft and hard
puffs including the Threshold setting. Once calibration has
been performed, your health care professional or authorized
dealer will save your settings.
Please note that all values must be greater than the Deadband
setting, for calibration to be performed successfully.

13.12 Single Switch Scanner

A single User Switch is connected to the Omni via one of the
1/8" (3.5mm) jack sockets.
If the Omni is configured to operate with a Single Switch
Scanner Type SID, the scan rate can be programmed to suit.
Refer to your health care professional or authorized dealer for
programing this parameter.

13.13 User Switch

With the exception of scanner operation the User Switch
provides the following functionality.
A short operation while not driving will select the different
wheelchair functions. See section 13.15.
A short operation while driving or making a seating adjustment
will stop all movement, i.e. an emergency stop function.
A long operation while not driving will put the Omni to sleep.
To wake the Omni, a short operation of the User Switch is
required.
The time of a long operation is preset to 1 Second, but it is
programmable from 0.5 to 5.0 Seconds. Refer to your health
care professional or authorized dealer for programming this
parameter.
247555 Rev. A
Puff
Soft Hard

13.14 Accessing Wheelchair Functions

The Omni can be programmed to access all the available
wheelchair functions in two ways – by Menu or by Sequence.
Your Omni control is programmed to "Menu" by default. The
Menu method is where an activation of the User Switch while in
Drive Mode will bring up an on-screen User Menu as shown in
Fig 13.9. SID direction commands are then used to navigate
the menu and select functions.
Should you wish to change this function to "Sequence", please
consult your health care professional or authorized dealer. The
Sequence method is where successive activations of the User
Switch will sequentially access all the wheelchair functions.
WARNING!
It is not advisable to program the menu options, 'speed
adjust' or 'profile select' if the Sequence method is being used
with scanning operation. Refer to your health care
professional or authorized dealer.
Seating
Drive
Profile
Sleep
Bluetooth Mouse
Fig.13.9
13.15 Display Background (Fig 13.10)
The color of the Omni screen background can be altered
via programming. Refer to section 7.5 or your authorized
dealer.
Seating
Drive
Profile
Sleep
Bluetooth Mouse
Fig.13.10
40
>
>
