IR MODE
On/Off
Channel Up
Channel Down
Volume Up
Fig.16.3
IR MODE
On/Off
Channel Up
Channel Down
Volume Up
Fig.16.4
IR MODE
On/Off
Channel Up
Channel Down
Volume Up
Fig.16.5
Scroll Up
Scroll Down
Select
247555 Rev. A
The dotted line is shown only as a reference to the
current position. It will not appear on the screen.
To navigate the IR Mode, using a joystick as an example
of an Input Device:
1. Reverse joystick deflections will highlight the appliance
2. Forward joystick deflections will highlight the appliance
3. Left or Right joystick deflections will enter the
4. Forward joystick deflections will highlight the option
5. Reverse joystick deflections will highlight the appliance
6. Left or Right joystick deflections will then activate the
For each Appliance there is a list of associated IR
commands. Using the TV example, Commands such as:
On/Off, Channel Up, Channel Down, Volume Up and
Volume Down may be displayed. When the Omni is
transmitting the selected Command, it is highlighted
with a red background (Fig 16.5).

16.3 Accessing the IR Set Up Menu

To access the IR set up on the Omni.
1. Hold the + and – keys on the Omni, this launches the
2. Use the four (4) navigation keys on the front screen of
S e t t i n g s
Menu
Fig.16.6
53
below the one currently displayed (Fig 16.1).
above the one currently displayed (Fig 16.2).
in all the IR Commands for that Appliance (Fig 16.3).
above the one currently displayed (Fig 16.2).
below the one currently displayed (Fig 16.4).
highlighted IR Command (Fig 16.5).
Settings menu (Fig 16.6).
the Omni. The Up/Down keys scroll up and down the
menu. The Left/Right keys select the highlighted
option (Fig 16.6).
