PROFILE - MODE BUTTON (LEFT PADDLE)
The Profile/Mode paddle switch allows the user to select the
available drive Profiles and operating Modes for the control
system. The selection sequence is through each of the available
Profiles and then each of the available Modes.
Depending on the way the control system has been programmed
a momentary screen may be displayed when a new Profile is
selected. Refer to section Momentary Screens for details.
The available Profiles and Modes are dependent on how the
control system has been programmed and the output devices that
are connected.
The Profile/Mode paddle switch is operated via reverse deflections
of the left paddle.
Depending on the way the control system has been programmed
a momentary screen may be displayed when the paddle is
operated. Refer to section Momentary Screens for details.
The default operation of the Speed paddle is momentary, i.e. the
speed setting will be increased upon forward deflections of the
paddle and decreased upon reverse deflections of the paddle.
The unit may be programmed to alter the timing and operation of
the Speed paddle, as well as changing it to operate continuously,
i.e. in a similar way to a rotary potentiometer, (also available).
EXTERNAL ON - OFF SWITCH JACK
This allows the user to turn the control system on and off using an
external switch, such as a Buddy-Button.
CAUTION!
The Joystick Module is supplied with rubber plugs that must be
inserted into the Jack Socket when no external device is connected.
TRANSMITTER
The CJSM2 includes an IR transmitter and receiver that allows the
CJSM2 to replicate commonly used IR devices, such as remote
controls for TV's, DVD's, Cable/Satellite or environmental controls
such as automatic door openers. Once correctly configured IR
Control can be performed using the Joystick (or other Input Device)
or from a Specialty Input Device that is connected to the system.
EXTERNAL PROFILE SWITCH JACK
This allows the user to perform the function of the Profile/Mode
paddle using an external switch, such as a Buddy Button.
If the control system is set for latched drive or latched actuator
control operation, then this input will provide the Emergency Stop
Switch function.
Alternative functions for this input are available via programing as
described below:
•
Switch pad to control multiple seat
•
Switch pad to control Bluetooth functions.
•
To set the operation of the control system in the event of a
failure in the connected switch or its wiring to this input.
247555 Rev. A
69
R-Net Control System
