Distance - Sunrise Medical Quickie R-Net Control System Instructions For Use Manual

Fig.7.6
Set Time
Display Time

Distance

Backlight
Background
Exit
Fig.7.7
Total Distance
Trip Distance e
Display Distance
Clear Trip Distance
Exit
Fig.7.8
Set Time
Display Time
Distance
Backlight
Background
Exit
247555 Rev. A
7.4 Distance
This sets the functionality of the odometer. To select the
distance option:
>
• Deflect the joystick backwards until "Distance" is highlighted
<12hr>
(Fig 7.6).
• Deflect the joystick to the right to select the option.
>
• The next screen appears (Fig 7.7).
<Blue>
Total Distance.
<Blue>
This is a value held in the Power Module and relates to the total
>
distance driven using that Power Module.
Trip Distance
This is a value held in the joystick module and relates to the
total distance driven since the last reset.
Display Distance
Sets whether Total Distance or Trip Distance appears as the
odometer display on the LCD Screen.
• Move the joystick backwards until "Display Distance" is
highlighted.
• Deflect the joystick to the right to select "Total" or "Trip."
012345
• Move the joystick backwards or forwards to exit "Display
012.3
Distance."
<Trip>
Clear Trip Distance
> To clear the Trip Distance value:
> • Deflect the joystick backwards until "Clear Trip Distance" is
highlighted.
• Move the joystick to the right to clear the displayed value.
• Deflect the joystick backwards or forwards to exit the "Clear
Trip Distance."
Exit
Move the joystick backwards until "Exit" is highlighted. A
right joystick deflection will return to the Settings Menu
(Fig 7.8).
>
>
>
<100%>
<Blue>
>
27 R-Net Control System
