14.7 Operation with Sip and Puff Type SIDs (Fig 13.6)
SIP and PUFF COMMAND
Hard Puff
Hard Sip
Soft Sip
Soft Puff
Fig.14.3
Driving is via a tube connected to the Omni's pneumatic input
and the User Switch is used to enter the User Menu.
For this type of SID, as well as a standard user switch, there
is the option of a pneumatic user switch.
Contact your authorized dealer.
There are four sip and puff commands, each of which relate to
a drive direction. The table Fig 14.3 shows the relationships.
In addition, the Omni can be programmed so that two
pneumatic operations, made within the period set by the
parameter Double Click Time, will mimic a short operation of
the User Switch in Standby.
Refer to your health care professional or authorized dealer.
247555 Rev. A
DIRECTION
Forward
Reverse
The standard R-Net programing parameter Joystick
Orientation may also be useful when using this type of SID.
Refer to your health care professional or authorized dealer.
Standard control of seating movements is via a Hard Puff or
Sip and a Soft Puff or Sip will select a different seat axis for
movement.
If required, it is possible to re-program the Omni to control
the seating movement in alternative ways.
Refer to your health care professional or authorized dealer.
For latched operation using this SID type, refer to Latched
Operation.
44
Left
Right
