RESTART (Fig 19.29)
When the control system requires a reboot; for example,
after a module reconfiguration, this symbol will be flashing.
Turn the chair off and back on.
SLEEP (Fig 19.30)
This symbol will be displayed for a short time before the R-
Net enters into a sleep state.
E-STOP (Fig 19.31)
If the control system is programmed for latched drive or
seating control operation, then it is normal for an Emergency
Stop Switch to be connected into the External Profile/Mode
Switch Jack.
If the Emergency Stop Switch is operated or disconnected,
this symbol will be displayed.
247555 Rev. A
Fig.19.29
Fig.19.30
Fig.19.31
75
R-Net Control System
