Backrest
5
Fig.15.8
Environment
6
Fig.15.9

PC Mouse

7
Fig.15.10

Speed Adjust

5
Fig.15.11
247555 Rev. A

15.10 Mode Screens

15.11 Actuator Mode (Fig 15.8)
Displays the sections of the chair currently selected for
movement, the name given to the selection and a direction
arrow showing what sort of movement is available.
15.12 Environment Mode (Fig 15.9)
When Environmental Mode is entered the following screen
will be displayed. Environmental control is used for
controlling third party equipment such as door openers.
15.13 PC Mouse (Fig 15.10)
When PC Mode is entered the following screen will be
displayed.
15.14 Speed Adjust (Fig 15.11)
When Speed Adjust Mode is entered the following screen will
be displayed.
49 R-Net Control System
