Speed Adjust
5
Fig.14.14
Lights
Left Turn
Right Turn
Hazards
Exit
Fig.14.15
Lights
Left Turn
Right Turn
Hazards
Exit
Fig.14.16
Lights
Left Turn
Right Turn
Hazards
Exit
Fig.14.17
247555 Rev. A

14.9 Speed Adjust Mode

A Speed Adjust Mode screen as shown in Fig 14.14, will
appear if the User Control parameter has been set to
Sequence (Refer to section 13.15).
Left and Right SID commands will adjust the maximum
speed setting.
The User Switch exits to the next available menu entry.
WARNING!
It is not advisable to program the menu option, 'speed adjust' if
the Sequence method is being used with a Single Switch
Scanner Type SID. Refer to your health care professional or
authorized dealer.

14.10 Lighting Control Mode

While in Lighting Control Mode, a screen as in Fig 14.15, will
< >
appear. Forward and Reverse SID commands will select each
lighting function. A Left or Right SID command will switch on
< >
the function (Fig 14.16). Another Left or Right SID command
will switch the function off.
< >
An operation of the User Switch or a Right SID command
< >
while Exit is highlighted (Fig 14.17) exits to the User Menu.
>
If User Control is set to Sequence, then selecting the Exit
option will sequence to the next available menu entry
(Refer to section 13.15).

14.11 Latched Operation

Latched operation is available with the Omni or a standard
>
JSM.
< >
Within the standard R-Net Programing, the relevant
parameters are: Latched Drive, Latched Actuators, Latched
< > Time out, and Latched Time out Beep. Please refer to your
health care professional or authorized dealer.
< >
>
< >
< >
< >
< >
>
