12.0 R-Net Omni Introduction

12.1 Introduction

The Omni is a universal speciality controls interface that
accepts signals from many different types of Speciality
Input Devices (SIDs) and translates them into
commands compatible with the R-Net control system.

12.2 Controls and Connections

The following diagrams show the Omni controls and
connections (Fig 12.0, 12.1, 12.2).
LCD Screen
Receiver
Profile
Mode
On/Off
Fig.12.0
Port 2 - D-Type
External On/Off Input Jack
247555 Rev. A
Programming and diagnostics should only be conducted by
health care professionals with in-depth knowledge of R-net
electronic control systems. Incorrect programing could result
in an unsafe setup of a vehicle for a user. Sunrise Medical
accept no liability for any losses of any kind if the programing
of the control system is altered from the factory preset values.
+/-
Navigation
Communications Cable
User Jack 2
35
WARNING!
User Jack 1
User Jack 1
Port 1 - D-Type
Sip and Puff Port
Transmitter
Charger Socket
Fig.12.1
Fig.12.2
