The GbE ports are used for the user network. Connect the other servers, other
PCs, UPS, etc. that are necessary for business via the network switch or hub.
Figure 4-2 GbE port locations
3.
If a PCIe card is mounted, connect a LAN cable and I/O cable to the respective
ports on the PCIe card.
4.
Connect the supplied power cords to the power supply units (A in
Insert the power cords straight into the power supply units all the way.
Figure 4-3 Power supply unit locations
Note - Do not connect to an outlet at this point.
Fujitsu M10-1/SPARC M10-1 Installation Guide ･ March 2019
72
A
A
Figure 4-3).
