Fujitsu ORACLE M10-1 Installation Manual page 17

Table 1-4 Required work when updating the firmware from XCP 2043 or earlier to XCP
2044 or later (continued)
Yes There is a logical
domain other than
the control domain
Table 1-5 indicates what information may need to be saved/restored when installing
or uninstalling the PCI expansion unit in a system with the firmware XCP 2044 or
later.
Table 1-5 Required work when installing or uninstalling the PCI expansion unit in the
system with the firmware XCP 2044 or later
PCI expansion unit Current domain
mounted? configuration
No factory-default
(Install) (Control domain
only)
No There is a logical
(Install) domain other than
the control domain
Yes factory-default
(Install/remove) (Control domain
only)
Yes There is a logical
(Install/remove) domain other than
the control domain
*1 Not required in XCP 2230 or later
Note - Execute the ldm list-constraints -x command to save it to an XML file, and execute the
ldm init-system -i command to restore it from an XML file. To display the information of
OpenBoot PROM environment, execute the printenv command at the ok prompt. For a
detailed procedure with these steps, see "1.7.3 How to Save/Restore the Logical Domain
Configuration Information and the OpenBoot PROM Environment Variable" in the PCI
Expansion Unit for Fujitsu SPARC M12 and Fujitsu M10/SPARC M10 Service Manual.
Required (XML file) Required
Reconfiguring Oracle VM Setting OpenBoot PROM
Server for SPARC config environment variables
again
Not required Not required
Required (XML file) Required (*1)
Not required Not required
Required (XML file) Required (*1)
Chapter 1 Understanding the Installation Flow 7
