Table C-1 SPARC M10-1 Workflow (from Installation to Initial Diagnosis) (continue d)
Work description
8. If there are optional components,
mount them on the SPARC M10-1 and
the PCI expansion unit.
(For details, see the service manual.)
9. Connect serial cables, LAN cables, and
power cords to the SPARC M10-1.
10. Connect the link cable and management
cable to the PCI expansion unit and the
SPARC M10-1.
Attach the core to the power cord, and
connect the power cord to the PCI
expansion unit.
11. Connect the system management
terminal to the SPARC M10-1.
12. Turn on the input power, and check
the status from the LED display on the
XSCF unit.
13. Log in to the XSCF.
14. Check the XCP version.
15. Set the altitude.
16. Set the time.
17. Perform the initial diagnosis test.
18. Confirm that that each component is
normally recognized, and no errors
occur.
Fujitsu M10-1/SPARC M10-1 Installation Guide ･ March 2019
132
Check
Checked Installation Guide reference
by
[ ] "3.5.1 Mounting optional components in the
SPARC
"3.5.2 Mounting optional components in the
PCI expansion
In the Fujitsu M10-1/SPARC M10-1 Service
Manual:
"Chapter 8 Maintaining the PCI Express Cards"
"Chapter 9 Maintaining the Internal Disks"
"Chapter 16 Maintaining the Motherboard
Unit/Memory"
[ ] "4.1 Connecting Cables to the SPARC
[ ] "4.2 Connecting Cables to the PCI Expansion
Unit"
[ ] "5.1 Connecting the System Management
Terminal to the
[ ] "5.2 Turning On the Input Power and Starting
the XSCF"
[ ] "5.3 Logging In to the
[ ] "5.4 Checking the XCP
[ ] "5.5 Checking the Altitude
* There is no need to set the altitude if it is
unknown.
[ ] "5.6 Checking the Time
[ ] "5.7 Performing a Diagnosis
The probe-scsi-all command and the
show-devs command are displayed as
command options in the diagnosis test.
Confirm that the installed disk capacity and
number of units, and the installation position
and device name of the PCI Express card are
correct.
[ ] "5.8 Checking the Component
M10-1"
unit"
Chassis"
XSCF"
Version"
Setting"
Setting"
Test"
Status"
M10-1"
