Figure 3-35     Attaching the cable support
For the Type-2 cable support
a. Tilt the cable support to align the circular holes at the rear of the groove with
Figure 3-36     Attaching the cable support (1)
D
Fujitsu M10-1/SPARC M10-1 Installation Guide ・ March 2019
66
C
(M3 screws)
the two screws of a cable support fixing bracket (D in
it. Level the cable support. Then, align the circular holes at the other side with
the two screws, and attach it.


Circular
hole sections
REAR
REAR
Figure
3-36), and attach
