Figure 3-32 Mounting in the rack
C
FRONT
A
9.
Secure the PCI expansion unit in the rack.
a. Push out the left and right slide locks on the front cover (C in
release the locks, and remove the front cover.
b. Tighten the two M6 screws at two locations on the front of the PCI expansion
unit (A in Figure
c. Insert the left and right hooks on the inside of the bottom of the front cover
into the grooves at the bottom front of the PCI expansion unit to attach the
front cover.
Note - A label with the serial number of the PCI expansion unit is affixed to the front cover.
Be sure to attach the front cover to the corresponding chassis.
A
FRONT FRONT
3-33) to secure it to the rack.
B
Figure
Chapter 3 Installing the System
3-32) to
