Fujitsu ORACLE M10-1 Installation Manual page 41

Figure 2-11 shows the cutoff characteristics of the circuit breaker.
Use a breaker with cutoff characteristics that have a Long-time delay type equivalent
to cutoff characteristic D (IEC/EN60898 or DIN VDE 0641 part II) shown in
2-11, or one with longer cutoff characteristics.
Figure 2-11 Distribution panel breaker characteristics on the equipment side
180
120
Minute
Second
0.06
0.04
0.02
0.01
60
40
20
10
6
4
2
1
40
20
10
6
4
2
1
0.6
0.4
0.2
B C
0.1
1 1.5 2 3 4 5 6 7 8 10
Current (Scaling factor against rated current)
Chapter 2 Planning and Preparing for System Installation
D
15 20 30 40 50 80 100
Figure
31
