Fujitsu ORACLE M10-1 Installation Manual page 39

Table 2-8 Electrical specifications (SPARC M10-1)
Item
Number of power cords
Power cord length (*1)
Redundancy
Frequency
Maximum input current
(*2)
Maximum power
consumption
Apparent power
Rush current (*3)
Leakage current (*3)
*1 The SPARC M10-1 is pulled out to perform maintenance. Therefore, you need to consider an extra length of 1.5 m
when ordering the power cord.
*2 The current that flows through each power cord in a redundant configuration is half the value listed in
*3 The value is per power cord.
Table 2-9 Electrical specifications (PCI expansion unit)
Item
Number of power cords
Power cord length
Redundancy
Frequency
Maximum input current (*1)
Maximum power consumption
Apparent power
Rush current (*2)
Leakage current (*2)
*1 The current that flows through each power cord in a redundant configuration is half the value listed in
*2 The value is per power cord.
Specification
Input voltage of 100 to 120 VAC
CPU type:
SPARC64 X
2
(1 for each PSU)
Maximum length of 3.0 m (9.8 ft.)
1+1 redundant
configuration
50 Hz/60 Hz, single phase
8.2 A
806 W
822 VA
40 A peak or less
1.75 mA or less
Specification
Input voltage of 100 to 120 VAC
2 (1 for each PSU)
Maximum length of 3.0 m (9.8 ft.)
1+1 redundant configuration
50 Hz/60 Hz, single phase
2.9 A
279 W
284 VA
40 A peak or less
1.75 mA or less
Input voltage of 200 to 240 VAC
CPU type: CPU type:
SPARC64 X+ SPARC64 X
2
(1 for each PSU)
Maximum length of 3.0 m (9.8 ft.)
1+1 redundant
configuration
50 Hz/60 Hz, single phase
8.7 A 4.0 A
849 W 783 W
866 VA 807 VA
40 A peak or less
1.75 mA or less
Input voltage of 200 to 240 VAC
2 (1 for each PSU)
Maximum length of 3.0 m (9.8 ft.)
1+1 redundant configuration
50 Hz/60 Hz, single phase
1.4 A
270 W
276 VA
40 A peak or less
1.75 mA or less
Chapter 2 Planning and Preparing for System Installation
CPU type:
SPARC64 X+
4.2 A
824 W
849 VA
Table 2-8.
Table 2-9.
29
