edge (B in
Figure
guide groove (E in
Figure 3-8 Attaching the right side of the CMA
E
B
A
d. While pushing out the green tag marked "CMA Release For ..." along the slide
rail on the left side of the chassis, insert the tip of the left side of the CMA.
e. Confirm that the CMA cannot be removed even when pulled forward. This
completes the attachment process.
3-8) of the slide rail on the right side of the chassis, along the
Figure
3-8).
Insert
Insert
D
C
Chapter 3 Installing the System
47
