4.1 The Initial Screen

Status/Data Transfer Indicator:

4.2 Quick Installation Screen

Press [ENT] to create a logical drive, the controller will start
initialization of one logical drive with all the connected SCSI drives
and automatically map the logical drive to LUN 0 of the first host
channel. The "Quick Installation" can only be performed when
there is no Logical Drive.
LCD Screen Messages
LCD Screen Messages
Product Model
SR2500
Ready
Status/Data Transfer Indicator
Ready There is at least one logical drive or logical volume
mapped to a host ID/LUN.
No Host No logical drive created or the logical drive has not
LUN yet been mapped to any host ID/LUN.
Indicates data transfer. Each block indicates
256Kbytes of data throughput.
Qu ick Lo gica l
Dr ive In stal l ¯
Firmware Version
v3.**
