Controller On-board:
2-Line LCD
CPU (_._) Temp Detected
Terminal
[3f23] Peripheral Device ALERT: CPU Temperature <high/low
threshold> Temperature Detected (_._C)
Event Type
What
The detected CPU temperature is higher or lower than the preset
Happens?
thresholds.
What to
Check the enclosure ventilation condition. If necessary, temperature
Do?
thresholds can be modified to suit different working conditions.
2-Line LCD
Board 1 (_._) Temp Detected
Terminal
[3f23] Peripheral Device ALERT: Board 1 Temperature <high/low
threshold> Temperature Detected (_._C)
Event Type
What
The detected main circuit board temperature is higher or lower than
Happens?
the preset thresholds.
What to
Check the enclosure ventilation condition. If necessary, temperature
Do?
thresholds can be modified to suit different working conditions.
2-Line LCD
Board 2 (_._) Temp Detected
Terminal
[3F21] ALERT: +5V Low Voltage Detected (current_voltage)
Event Type
What
The detected main circuit board temperature is higher or lower than
Happens?
the preset thresholds.
What to
Check the enclosure ventilation condition. If necessary, temperature
Do?
thresholds can be modified to suit different working conditions.
2-Line LCD
Fan_ Not Installed
Terminal
[3F22] Peripheral Device ALERT: Controller FAN_ Not Present or
Failure Detected
Event Type
What
This event refers to the cooling fan in front panel. Check cable
Happens?
connection and see if the fan(s) has failed.
What to
Check cable connection and see if the fan(s) is rotating. Some OEM
Do?
solutions may have removed front panel fans and the "fan detect"
signals should be disabled by setting jumpers. Please refer to your
Hardware Manual for more details.
2-Line LCD
Fan (_._) Speed Detected
Terminal
[3F22] Peripheral Device ALERT: Controller FAN_ <high/low
threshold> Speed Detected (_RPM)
Event Type
What
This event refers to the cooling fan in front panel. Higher or Lower
Happens?
rotation speed detected.
What to
Contact your system vendor for replacing the cooling fan.
Do?
Event Messages
!Alert
"Warning
!Alert
"Warning
!Alert
"Warning
!Alert
"Warning
!Alert
"Warning
"Notification
"Notification
"Notification
"Notification
"Notification
D-23
