Chapter
11 11 11 11
In addition to saving the configuration data in NVRAM to disk,
keeping a hard copy of the controller configuration is also
recommended. This will speed the recreation of the RAID in the
event of a disaster.
The following tables are provided as a model for recording the
configuration data.
As a general rule, the configuration data in the NVRAM should be
saved to disk or as a file (using RAIDWatch Manager) whenever a
configuration change is made (see Chapter 6 and 7).

11.1 View and Edit Logical Drives

Logical Drive Information

LG ID LV
Record of Settings
Record of Settings
RAID Level size (MB) status 1 2 3 O C
11-1
